ROTOR DISC » RN1654V

RN1654V

Specification

Type
Vented
Outter Ø
314
Num. of holes
5
Disc Thickness (Max)
20
Height
60
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
190
Disc Thickness (Min)
18.4
Structure Material
G3000

Cross Reference

HYUNDAI
584113N020
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   Centennial / Equus

01.13~01.15 3800 G6DJ BHL13 RN1711V PN0633 RN1654V PN0415 FN0783
09.09~05.13 3800 G6DK BHL08 RN1711V PN11002PN0633 RN1654V PN0415 FN0666

HYUNDAI   »   Genesis Coupe

11.08~03.12 2000 G4KF DK08 RN1711V PN0150SPN0633 RN1654V PN0415 FN0666
