ROTOR DISC » RN1693
Specification
Type
Solid
Front/Rear
Rear
Outter Ø
259
Num. of holes
5
Disc Thickness (Max)
9
Height
43.4
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
147
Disc Thickness (Min)
8
Structure Material
G3000
Cross Reference
SUZUKI
55611-61M00
SUZUKI
55611-61M00-000
SUZUKI
55611-61M20
SUZUKI
55611-61M20-000
SUZUKI
55611-61M21
SUZUKI
55611-70L00
SUZUKI
55611-72L00
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.10~ | 1400 | K14B | AZG414 | RN29001V | PN5562 | DN1369RN1955RN1693 | FN9991PN9808 | |
| 03.10~ | 1400 | K14B | ZC82S LHD | RN2245VRN29001V | PN5562PN9529 | RN1955RN1693DN1369 | PN9808FN9991 | |
| 03.10~03.13 | 1400 | K14B | ZC82S RHD | RN29001V | PN5562 | RN1693RN1955DN1369 | PN9808FN9991 | |
| 03.13~02.17 | 1400 | K14B | ZC82S RHD | RN29001VRN2245V | PN5562PN9529 | RN1955RN1693DN1369 | FN9991PN9808 | |
| 12.11~ | 1600 | M16A | EZC32S | RN2449V | PN5562 | RN1693DN1369RN1955 | PN9808FN9991 | |
| 10.09~02.13 | 1600 | M16A | ZA32S LHD | RN2449V | PN5562 | RN1693DN1369RN1955 | FN9991PN9808 | |
| 10.09~02.13 | 1600 | M16A | ZC32S LHD PR | RN2449V | PN5562 | RN1693DN1369RN1955 | PN9808FN9991 | |
| 12.11~ | 1600 | M16A | ZC3B | RN2449V | PN5562 | RN1693RN1955 | PN9808 |
| 08.16~ | 1000 | K10C | AKK310# | RN1692V | PN9809 | RN1693 | PN9808 | |
| 08.16~ | 1400 | K14C | AKK414# | RN1692V | PN9809 | RN1693 | PN9808 | |
| 12.13~ | 1600 | M16A | JYB22S LHD | RN1692V | PN9809 | RN1693 | PN9808 | |
| 01.16~ | 1600 | M16A | YA22S LHD | RN1692V | PN9809 | RN1693 | PN9808 | |
| 12.13~ | 1600 | M16A | YA22S RHD | RN1692V | PN9809 | RN1693 | PN9808 | |
| 12.13~01.16 | 1600 | M16A | YB22S RHD | RN1692V | PN9809 | RN1693 | PN9808 | |
| 01.16~ | 1600 | M16A | YB22S RHD | RN1692V | PN9809 | RN1693 | PN9808 |
| 02.18~ | 1000 | K10C-T | APK310 | RN1692V | PN9809 | RN1693 | PN9808 | |
| 10.14~10.18 | 1400 | K14C | APK414 | RN1692V | PN9809 | RN1693 | PN9808 | |
| 10.18~ | 1400 | K14C | APK414-3 LHD | RN1692V | PN9809 | RN1693 | PN9808 | |
| 02.18~ | 1400 | K14C | APK414-3 RHD | RN1692V | PN9809 | RN1693 | PN9808 | |
| 02.18~ | 1400 | K14D | APK414-3 LHD | RN1692V | PN9809 | RN1693 | PN9808 | |
| 10.14~10.18 | 1600 | D16AA | APK416D | RN1692V | PN9809 | RN1693 | PN9808 | |
| 10.14~10.18 | 1600 | M16A | APK416 | RN1692V | PN9809 | RN1693 | PN9808 | |
| 10.18~ | 1600 | M16A | APK416-3 LHD | RN1692V | PN9809 | RN1693 | PN9808 | |
| 02.18~ | 1600 | M16A | APK416-3 RHD | RN1692V | PN9809 | RN1693 | PN9808 |
