ROTOR DISC » RN1686V
Specification
Type
Vented
Front/Rear
Front
Outter Ø
321
Num. of holes
5
Disc Thickness (Max)
30
Height
51
Centering Diameter
67.4
Pitch Circle Ø
120
Drum Ø:
160
Disc Thickness (Min)
28.6
Structure Material
G3000
Cross Reference
GM
13501308
GM
13501320
GM
13502214
GM
13579150
GM
23118055
GM
23118530
OPEL
05 69 064
OPEL
05 69 083
OPEL
05 69 422
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.11~08.15 | 3600 | LFX | 1E#37 | RN1686V | PN34002 | PN51007 | ||
| 01.15~ | 3600 | LGX | P90D | RN2375VRN1686V | PN34002PN0813S | PN51007PN52020 | FN0784 | |
| 03.09~08.11 | 3600 | LLT | 1E#37 | RN1686V | PN0713PN34002 | PN51007 |
| 01.10~01.18 | 2400 | LAF | 1L#26 | RN1686V | PN0839 | RN2213V | PN0479 | FN0667 |
| 02.15~03.17 | 2400 | LEA | 1L#26 | RN1686V | PN34002PN0713 | RN2213V | PN0479 | FN0667 |
| 05.12~01.16 | 2000 | LBS/ A20DTH | RGB69 | RN1686V | PN0839 | RN1685 | PN0840 | |
| 01.12~01.17 | 2400 | LE9 | GA69 | RN1684VRN1686V | PN0713PN0839PN34002 | RN1685RN1687V | PN0581PN0840 | |
| 01.12~01.17 | 3000 | LFW | LTZ | RN1686V | PN34002PN0713 | RN1687V | PN0840 |
