ROTOR DISC » RN1647V

RN1647V

Specification

Type
Vented
Outter Ø
260
Num. of holes
4/6
Disc Thickness (Max)
24
Height
41
Centering Diameter
60
Pitch Circle Ø
100
Front/Rear
Front
Disc Thickness (Min)
22.4
Drum Ø:
125.8
Structure Material
G3000

Cross Reference

BENDIX
562196B
GM
09127967
GM
9196050
OPEL
05 69 000
OPEL
569000
OPEL
9127967
OPEL
95526646
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHEVROLET (GM)   »   Corsa

09.05~12.11 1600 B16NE F68 RN1647V PN0361

CHEVROLET (GM)   »   Montana

08.03~10.10 1800 LJ1 F80 RN1647V PN0361 FN0599

HOLDEN   »   Barina

02.01~12.05 1400 Z14XE XC RN1647V PN0361 FN0533PN0192

OPEL   »   Combo-C

06.04~01.12 1300 Z13DTJ F25 RN1647VRN1202V PN0355 DN1593RN1648 FN0599PN0329
09.01~08.04 1600 Z16SE RN1647V PN0361 RN1648 FN0599PN0329
06.05~01.12 1600 Z16YNG RN1647V PN0361 RN1648 PN0329
09.01~08.04 1700 Y17DT RN1647V PN0361 RN1648 PN0329FN0599
09.01~08.04 1700 Y17DTL RN1647V PN0361 RN1648 PN0329

OPEL   »   Corsa C

09.03~11.06 1300 Z13DT F25 RN1647VRN1202V PN0355PN0361 RN1648 PN0329

OPEL   »   Tigra Twin-Top

09.04~01.10 1400 Z14XEP 97 RN1647V PN0361 DN1852 FN11622PN0192
