ROTOR DISC » RN1560V
Specification
Type
Vented
Outter Ø
256
Num. of holes
4
Disc Thickness (Max)
24
Height
45.5
Centering Diameter
60
Pitch Circle Ø
100
Front/Rear
Front
Drum Ø:
125
Disc Thickness (Min)
21
Structure Material
G3000
Cross Reference
GM
13502001
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.11~10.15 | 1200 | A12XER / LDC | 1JC48 RHD HB | RN1560V | PN0632 | DN1685 | FN0727 | |
| 09.11~10.15 | 1200 | A12XER / LDC | 1JG48 LHD HB | RN1560V | PN0632 | DN1685 | FN0727 | |
| 10.11~10.15 | 1300 | LDV / A13DTC | 5DR HB EL | RN34001VRN1560V | PN0391PN0632 | DN1684 | FN0760FN11174 | |
| 10.11~10.15 | 1400 | A14XER / LDD | 1HJ69 | RN1560V | PN0632 | DN1685 | FN0727 | |
| 10.11~10.15 | 1600 | F16D4 / LDE | 1J_ HB | RN1560V | PN0632 | DN1685 | FN0727 |
| 01.13~01.19 | 1500 | L2C | 1JX69 UZ RU | RN1560V | PN0627PN0632 | DN1685 | FN0727 | |
| 05.17~ | 1800 | LSJ | LT | RN2491VRN1560V | PN0627PN0957PN0632 | DN1685 | FN0727 |
| 01.14~03.19 | 1400 | A14XER | TA48 | RN1560VRN34001V | PN0391PN0632 | DN1684DN1685 | FN0760FN0727 | |
| 06.11~12.17 | 1400 | A14XER | TA69 | RN34001VRN1560V | PN0391PN0632 | DN1684DN1685 | PN0392FN0727 | |
| 08.11~01.17 | 1400 | A14XER / LDD | 1J#69 SDN RHD | RN1560V | PN0632 | DN1685 | FN0727 | |
| 08.11~01.17 | 1600 | F16D4 / LDE | 1JD69 SDN LHD | RN1560V | PN0632 | DN1685 | FN0727 |
