DRUM BRAKE » DN1878

Specification

Outter Ø
274
Num. of holes
4
Centering Diameter
60
Height
63
Pitch Circle Ø
100
Drum Ø
230
Structure Material
G3000
Hole Ø
14

Cross Reference

GM
94737568
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
02.13~07.15 1300 LDV / A13DTC 1KJ75 RN1560V PN0632 DN1878 FN0760
02.13~07.15 1500 L2B 1KJ75 RN1560V PN0632 DN1878 FN0760

Exemption from liability: the catalog data is advisory and can be used for reference only
