ROTOR DISC » RN2348V

Specification

Type
Vented
Outter Ø
262
Num. of holes
4
Disc Thickness (Max)
21
Disc Thickness (Min)
19
Height
44.7
Centering Diameter
61
Pitch Circle Ø
100
Front/Rear
Front
Structure Material
G3000
Hole Ø:
12.7
Drum Ø:
141.8

Cross Reference

HONDA
45251-T5R-A02
HONDA
45251-TZA-J00
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.23~ 1500 LEB8 GN3 RHD RN2348V PN8868 RN2349 PN8821
10.19~ 1300 L13B GR1 RN2348V PN8868 RN2349 PN8821
10.19~ 1300 L13B GR2 RN2348V PN8868 RN2349 PN8821
10.19~ 1300 L13B GR7 RN2348V PN8868 RN2349 PN8821
01.14~06.17 1500 L15B GK5 KP LHD RN2348V PN8868 DN1389 FN28002
01.14~06.17 1500 L15B GK5 US/CND LHD RN2348V PN8868 DN1389 FN28002
10.19~ 1500 L15Z GS4 RHD RN2348V PN8868 RN2349 PN8821
10.19~ 1500 LEB GR3 JPN RN2348V PN8868 RN2349 PN8821
10.19~ 1500 LEB GR3 RHD RN2348V PN8868 RN2349 PN8821
10.19~ 1500 LEB GR4 JPN RN2348V PN8868 RN2349 PN8821
10.19~ 1500 LEB GR6 JPN RN2348V PN8868 RN2349 PN8821
10.19~ 1500 LEB GR8 JPN RN2348V PN8868 RN2349 PN8821
02.20~ 1500 LEB8 GR3 RN2348V PN8868 RN2349 PN8821
03.17~12.21 1500 L15Z9 GH8 RN2348V PN8868 DN1389 FN28002

Exemption from liability: the catalog data is advisory and can be used for reference only
