NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2322V

Product
Application

ROTOR DISC » RN2322V

Specification

Type

Vented

Outter Ø

322

Num. of holes

6

Hole Ø:

13.6

Disc Thickness (Max)

30

Disc Thickness (Min)

27

Height

59

Centering Diameter

78

Pitch Circle Ø

139.7

Front/Rear

Rear

Structure Material

G3000

Drum Ø:

184

Cross Reference

GREAT WALL

3502011XKV08A

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HAVAL » H9

11.17~02.21	2000	GW4C20A		RN2321V	PN0458	RN2322V	PN6017
11.17~01.24	2000	GW4D20T		RN2321V	PN0458	RN2322V	PN6017
