BRAKE SHOE » FN0756

FN0756

Specification

Radius
104.1
Width
39
Thickness
5.5
Pcs In Set
4

Cross Reference

FMSI
S1078-1731
HYUNDAI / KIA
58305A9A10
KIA
58305-A9A00
KIA
58305-A9A10
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

KIA   »   Carnival / Sedona

04.14~01.21 2200 D4HB WAGON LONG - 11P RN2409V PN0711 PN0457 FN0756
04.14~01.21 2200 D4HB WAGON LONG - 7P RN2409V PN0711PN0588 PN0457 FN0756
04.14~03.18 2200 D4HB WAGON LONG - 8P RHD RN2409V PN0711 PN0457 FN0756
03.18~08.20 2200 D4HB WAGON LONG - 8P RHD RN2409V PN0711 PN0457 FN0756
04.14~03.18 2200 D4HB WAGON LONG - 9P RN2409V PN0711 PN0457 FN0756
04.14~01.21 3300 G6DF WAGON LONG - 11P RHD RN2409V PN0711 PN0457 FN0756
09.14~03.18 3300 G6DF WAGON LONG - 8P RN2409V PN0711 PN0457 FN0756
04.14~01.21 3300 G6DH WAGON LONG - 7P RN2409V PN0711 PN0457 FN0756

KIA   »   Carnival / Sedona 18

02.18~07.20 2200 D4HB WAGON LONG - 9P PN0711 PN0457 FN0756
02.18~07.20 3300 G6DF WAGON LONG - 8P PN0711 PN0457 FN0756
02.18~07.20 3300 G6DM WAGON LONG - 8P RN2409V PN0711 PN0457 FN0756
