ROTOR DISC » RN2283

Specification

Type
Solid
Outter Ø
282
Num. of holes
5
Hole Ø:
12.7
Disc Thickness (Max)
10
Disc Thickness (Min)
8
Height
36.6
Centering Diameter
64.1
Pitch Circle Ø
114.3
Front/Rear
Rear
Structure Material
G3000
Drum Ø:
142.5

Cross Reference

HONDA
42510-TBF-A00
HONDA
42510-TGN-G00
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.17~ 1000 P10A2 FK6 RN1600V PN8863 RN2283 PN8813
05.16~08.19 1500 L15B FC1 LHD RN1600V PN8863 RN2283 PN8813
05.16~03.21 1500 L15B7 FK7 RHD RN1600V PN8863 RN2283 PN8813
05.17~03.21 1600 N16A1 FC8 RN1600V PN8863 RN2283 PN8813
01.18~ 1600 N16A1 FK9 RN1218V PN8485 RN2283RN2157 PN8813

Exemption from liability: the catalog data is advisory and can be used for reference only
