ROTOR DISC » RN2235V
Specification
Type
Vented
Outter Ø
285
Num. of holes
5
Hole Ø:
13
Disc Thickness (Max)
17
Disc Thickness (Min)
15.4
Height
46.4
Centering Diameter
58
Pitch Circle Ø
100
Front/Rear
Rear
Structure Material
G3000
Drum Ø:
148
Cross Reference
SUBARU
26700-FL000
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 12.16~ | 1600 | FB16 | GK2 | RN2454V | PN7805 | RN2235V | PN7804 | |
| 09.16~ | 1600 | FB16A | GK3K | RN2454V | PN7805 | RN2235V | PN7804 | |
| 08.16~ | 1600 | FB16A | GT2 JPN | RN2454V | PN7805 | RN2235V | PN7804 | |
| 08.16~ | 1600 | FB16A | GT3 JPN HB | RN2454V | PN7805 | RN2235V | PN7804 | |
| 09.16~ | 1600 | FB16A | GT3K RHD | RN2454V | PN7805 | RN2235V | PN7804 | |
| 09.16~ | 1600 | FB16A | GT3L LHD | RN2454VRN2166V | PN7805 | RN2235V | PN7804 | |
| 10.16~ | 2000 | FB20 | GT6 JPN | RN2454V | PN7805 | RN2235V | PN7804 | |
| 08.16~ | 2000 | FB20C | GK7 JPN | RN2166V | PN7805 | RN2235V | PN7804 | |
| 08.16~ | 2000 | FB20C | GK7 RHD | RN2454V | PN7805 | RN2235V | PN7804 | |
| 03.16~10.19 | 2000 | FB20C | GT7 JPN | RN2454V | PN7805 | RN2235V | PN7804 | |
| 03.16~10.19 | 2000 | FB20C | GT7 RHD | RN2454V | PN7805 | RN2235V | PN7804 |
| 05.17~ | 1600 | FB16A | GT3 JPN SUV | RN2166V | PN7805 | RN2235V | PN7804 | |
| 05.17~ | 1600 | FB16A | GT3 LH | RN2166V | PN7805 | RN2235V | PN7804 | |
| 03.17~09.20 | 1600 | FB16A | GT3 RH | RN2166V | PN7805 | RN2235V | PN7804 | |
| 09.20~ | 1600 | FB16A | GT3 RH | RN2166V | PN7805 | RN2235V | PN7804 | |
| 03.17~ | 2000 | FB20C | GT7 RHD | RN2166V | PN7805 | RN2235V | PN7804 | |
| 03.17~ | 2000 | FB20D | GT7 LHD | RN2166V | PN7805 | RN2235V | PN7804 | |
| 03.17~ | 2000 | FB20W | GTE | RN2166V | PN7805 | RN2235V | PN7804 |
