DRUM BRAKE » DN1728

Specification

Outter Ø
296
Num. of holes
5
Hole Ø
14.7
Centering Diameter
70.7
Height
73.7
Pitch Circle Ø
115
Drum Ø
250
Structure Material
G3000

Cross Reference

BENDIX
PDR0761
GM
10304169
GM
10306594
GM
10421516
SATURN
10306594
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.03~05.09 3400 LNJ 1L#26 RN1622V PN0378PN0068 DN1728RN1677V PN0479 FN0667
09.05~09.09 3400 LNJ 2F#26 RN1622V PN0068PN0378 RN1677VDN1728 PN0479 FN0667

Exemption from liability: the catalog data is advisory and can be used for reference only
