DRUM BRAKE » DN1652

Specification

Outter Ø
346
Num. of holes
6
Centering Diameter
78.6
Height
97.4
Pitch Circle Ø
139.7
Drum Ø
283.2
Structure Material
G3000
Hole Ø
15

Cross Reference

BENDIX
PDR0623
GM
15016408
GM
15650087
GM
15693466
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.99~12.00 5700 L31 PN0308 DN1652 FN11097
10.94~04.00 5700 L05 GMT400 PN0308 DN1652 FN11097
10.94~04.00 5700 L31 GMT400 PN0308 DN1652 FN11097

Exemption from liability: the catalog data is advisory and can be used for reference only
