DRUM BRAKE » DN1404

Specification

Outter Ø
297
Num. of holes
5
Hole Ø
12.7
Centering Diameter
108.3
Height
69.8
Pitch Circle Ø
139,7
Drum Ø
254.2
Structure Material
G3000

Cross Reference

SUZUKI
43511-52D00
SUZUKI
43511-52D00-000
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.04~12.06 2000 RHW JA420WD RN1140V PN9806 DN1404 FN9968
05.01~08.03 2700 H27A TX92V LHD RN1140V PN9382 DN1404 FN9968
08.03~01.07 2700 H27A TX92V LHD RN1140V PN9382 DN1404 FN9968
05.01~01.07 2700 H27A TX92W RHD RN1140V PN9382 DN1404 FN9968

Exemption from liability: the catalog data is advisory and can be used for reference only
