NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1491V

Product
Application

ROTOR DISC » RN1491V

Specification

Type

Vented

Disc Thickness (Max)

17

Num. of holes

5

Height

29

Centering Diameter

108.3

Front/Rear

Front

Pitch Circle Ø

139.7

Outter Ø

286

Drum Ø:

180

Disc Thickness (Min)

15

Structure Material

G3000

Cross Reference

GM

19175152

GM

30022977

GM

30024673

MAZDA

1A51-33-25X

MAZDA

1A51-33-25XA

SUZUKI

5521165D00

SUZUKI

5521165D01

SUZUKI

5521165D02

SUZUKI

5521167D00

SUZUKI

5521167D01

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

CHEVROLET (GM) » Tracker

01.99~01.05

2000

L34

CE103

RN1491V

PN9301

DN1676 DN1405

FN9958

MAZDA » Proceed Levante

11.97~09.99

2000

J20A

TJ52W

RN1491V

PN9301

DN1405

FN9958

SUZUKI » Escudo

11.97~11.00	1600	G16A	TA02W	RN1491V	PN9301		FN9958
11.97~04.00	1600	G16A	TD02W	RN1491V	PN9301		FN9958
11.97~09.02	2000	J20A	TA52W	RN1491V	PN9301		FN9958
11.97~04.00	2000	J20A	TD52W	RN1491V	PN9301		FN9958

SUZUKI » Grand Vitara

01.98~12.04	1600	G16B	TB03V	RN1491V	PN9301	DN1676	FN9958
01.98~09.05	1600	G16B	TD02V	RN1491V	PN9301	DN1676	FN9958
