BRAKE PADS » PN0570

Specification

Length-1
133
Width-1
48.8
Thickness-1
16.8
Length-2
133
Width-2
18.8
Thickness-2
16.8
Pcs In Set
4

Cross Reference

BENDIX AUS
DB2208
CHEVROLET
9668 2858
FMSI
D1590-8801
GM
42517127
GM
42785996
GM
94564512
GM
96682858
KASHIYAMA
D11271MH
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.10~01.16 1000 B10D1 MA48 RN1206V PN0570 DN1680 FN11174
01.13~01.16 1000 LFM / B10D2 RCE48 LHD RN1206V PN0570 DN1680
01.10~01.16 1000 LMT / B10D1 1C#48 RN1206V PN0570 DN1680 FN11174
01.11~01.21 1200 B12D1 / LMU 1C#48 LHD RN1206V PN0570 DN1680 FN11174
01.12~01.16 1200 B12D1 / LMU CT48 RHD RN1206V PN0570 DN1680 FN11174
01.20~ 1200 B12D1 / LMU CT69 PN0570 FN11174
01.10~12.15 1000 LMT / B10D1 RC#48 RN1206V PN0570 DN1680 FN11174
01.10~12.15 1200 PN0570
02.16~ 1200 B12D2 R2 RN1206V PN0570 DN1680 FN11174

Exemption from liability: the catalog data is advisory and can be used for reference only
