ROTOR DISC » RN1345V

Specification

Type
Vented
Disc Thickness (Max)
20
Num. of holes
4
Height
41.7
Centering Diameter
74
Front/Rear
Front
Outter Ø
255

Cross Reference

BENDIX
561440B
TOYOTA
43512-28050
TOYOTA
43512-28051
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.85~01.92 1800 1C CM35RV RN1345V PN1328 FN2232
09.85~01.92 1800 2Y-U YM30G RN1345V PN1328 FN2232
05.83~01.92 2000 3Y-EU YR21G RN1342VRN1345V PN1328 FN2220

Exemption from liability: the catalog data is advisory and can be used for reference only
