ROTOR DISC » RN1030V
Specification
Type
Vented
Disc Thickness (Max)
23
Num. of holes
4
Height
34
Centering Diameter
92
Front/Rear
Front
Outter Ø
259.6
Pitch Circle Ø
114.3
Disc Thickness (Min)
21
Drum Ø:
160
Structure Material
G3000
Cross Reference
BENDIX
561671B
HONDA
45251-SM4-020
HONDA
45251SM4000
HONDA
45251SM4010
HONDA
45251SN7E40
ROVER
GBD90836
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.89~09.93 | 1800 | F18A | CB1 | RN1030V | PN8223 | RN1054 | PN8398FN5520 | |
| 02.96~01.98 | 1800 | F18A# | CE7 EU | RN1030V | PN8254PN8293 | RN1054 | PN8398 | |
| 01.94~12.96 | 1800 | F18A/3/4 | EURO | RN1030V | PN8293PN8254 | RN1054 | PN8398 | |
| 10.93~09.97 | 1800 | F18B | CD3 | RN1030V | PN8223 | RN1054 | FN5520PN8398 | |
| 01.96~12.97 | 1800 | F18B | EURO | RN1030V | PN8223 | RN1054 | PN8398FN5520 | |
| 01.99~12.00 | 2000 | 20T2N | EURO | RN1030V | PN8293 | RN1054 | PN8398 | |
| 01.96~12.98 | 2000 | 20T2N# | CF1 EU | RN1030V | PN8293 | RN1054 | PN8398 | |
| 01.96~12.96 | 2000 | 20T2N14/15 | EURO | RN1030V | PN8293 | RN1054 | PN8398 | |
| 09.89~09.93 | 2000 | F20 | CB4 | RN1030V | PN8223 | RN2071 | PN8398 | |
| 09.89~09.93 | 2000 | F20A | CB3 | RN1030V | PN8223 | RN1054 | PN8398 | |
| 04.90~02.94 | 2000 | F20A1/3/8 | EURO | RN1030V | PN8484 | RN1054 | FN5524PN8398 | |
| 09.93~09.97 | 2000 | F20B | CD4 JPN | RN1030V | PN8223 | RN1054 | PN8398FN5520 | |
| 09.93~09.97 | 2000 | F20B | CD4 RHD | RN1030V | PN8223PN8484 | RN1054 | PN8398FN5520 | |
| 01.93~12.98 | 2000 | F20B1 | EURO | RN1030V | PN8484 | RN1054 | FN5524PN8398 | |
| 02.93~09.98 | 2000 | F20Z1/2 | CC7 EU | RN1030V | PN8293 | RN1054 | PN8398 | |
| 01.93~12.96 | 2000 | F20Z1/2 | EURO | RN1030V | PN8293PN8254 | RN1054 | PN8398 | |
| 01.92~02.94 | 2200 | F22A | CB7 | RN1030V | PN8223PN8814 | RN1054 | PN8398 | |
| 01.90~12.93 | 2200 | F22A | EURO | RN1030V | PN8484PN8814 | RN1054 | PN8398FN5524 | |
| 09.89~08.93 | 2200 | F22A3 | CB7 | RN1030V | PN8814PN8223 | DN1387RN2071 | PN8398FN5524 | |
| 10.94~12.98 | 2200 | F22B1 | CD5 RHD | RN1030V | PN8484 | RN1054 | PN8398 | |
| 01.94~12.97 | 2200 | F22B1-5 | EURO | RN1030V | PN8223 | RN1054 | PN8398FN5524 | |
| 01.96~12.97 | 2200 | F22Z4 | EURO | RN1030V | PN8484PN8254 | RN1054 | PN8398 |
| 08.93~12.98 | 2200 | F22B | CD9 US | RN1030V | PN8484PN8254 | RN1054 | PN8398 | |
| 08.93~12.98 | 2200 | F22B2 | EURO | RN1030V | PN8484PN8254 | RN1054 | PN8398 |
