ROTOR DISC » RN2685V

Specification

Type
Vented
Outter Ø
315
Num. of holes
5
Hole Ø:
12.6
Disc Thickness (Max)
20
Disc Thickness (Min)
18.4
Height
78.5
Centering Diameter
96.3
Pitch Circle Ø
139.7
Drum Ø:
190.1
Front/Rear
Rear
Structure Material
G3000

Cross Reference

KIA
58411-3E500
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.06~05.09 2500 D4CB A2 BL06 LHD RN1313V PN0441 RN2685V PN0798
04.06~05.09 2500 D4CB A2 BL06 RHD RN1313V PN0441 RN2685V PN0798
04.06~05.09 3300 G6DB JC RN1313V PN0441 RN2685V PN0798
04.06~05.09 3800 G6DA BL06 LHD RN1313V PN0441 RN2685V PN0798
04.06~05.09 3300 G6DB PBL06 US PN0115 RN2685V PN0797 FN11005
04.06~05.09 3800 G6DA PBL06 US RN1313V PN0441PN0115 RN2685V PN0798PN0797 FN11005

Exemption from liability: the catalog data is advisory and can be used for reference only
