ROTOR DISC » RN2097V

Specification

Type
Vented
Outter Ø
255
Num. of holes
5
Disc Thickness (Max)
25
Disc Thickness (Min)
23
Height
49.2
Centering Diameter
55
Pitch Circle Ø
100
Drum Ø:
140
Structure Material
G3000

Cross Reference

TOYOTA
43512-47060
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.19~ 1800 2ZRFXE ZWE211L RN2097V PN0540 RN1626RN2140 PN1865PN1519
01.19~ 1800 2ZRFXE ZWE211R RN2097V PN0540 RN2140RN1626 PN1865PN1519
01.19~ 1800 2ZRFXE ZWE213L RN2097V PN0540 RN1626RN2140 PN1519PN1865
11.15~12.18 1800 2ZR-FXE ZVW50 RN2097V PN0540 RN1626 PN1519
11.15~12.18 1800 2ZR-FXE ZVW50L RN2097V PN0540 RN1626 PN1519
11.15~11.22 1800 2ZR-FXE ZVW50R RN2097V PN0540 RN1626 PN1519
11.15~11.22 1800 2ZR-FXE ZVW51 RN2097V PN0540 RN1626 PN1519
11.15~12.18 1800 2ZR-FXE ZVW51L RN2097V PN0540 RN1626 PN1519
11.15~11.22 1800 2ZR-FXE ZVW55 RN2097V PN0540 RN1626 PN1519
09.16~11.22 1800 2ZR-FXE ZVW52L RN2097V PN0540 RN1626 PN1519

Exemption from liability: the catalog data is advisory and can be used for reference only
