ROTOR DISC » RN2638V

Specification

Type
Vented
Outter Ø
281
Num. of holes
5/9
Hole Ø:
15.3
Disc Thickness (Max)
24
Disc Thickness (Min)
22
Height
49.5
Centering Diameter
65
Pitch Circle Ø
112
Front/Rear
Front
Structure Material
G3000

Cross Reference

FAW-VW
5QL 615 301
FAW-VW
L5QL 615 301
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.19~ 1400 DJSA 0L1 RN2638V PN8040 RN33004RN2639 PN33003PN6042
06.19~ 1400 DJSA 0L2 RN2638V PN8040 RN33004RN2639 PN6042PN33003

Exemption from liability: the catalog data is advisory and can be used for reference only
