NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1893V

ROTOR DISC » RN1893V

Specification

Type

Vented

Outter Ø

262.7

Num. of holes

6

Disc Thickness (Max)

26

Height

37

Centering Diameter

81

Pitch Circle Ø

103

Front/Rear

Front

Drum Ø:

130

Disc Thickness (Min)

24

Structure Material

G3000

Cross Reference

NISSAN

40206-21T00

NISSAN

40206-21T01

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

NISSAN » Atlas

06.99~06.07	2000	KA20DE	H4F23	RN1893V	PN2204	DN1303	FN1163
01.92~06.95	2000	NA20S	K2F23	RN1893V RN1333V	PN2344 PN2204 PN2105	DN1296	FN1174 FN1179 FN2280
01.92~06.99	2000	NA20S	K4F23	RN1893V	PN2204		FN1163
10.88~07.90	2000	Z20S	PF22	RN1893V	PN2204		FN1146
02.82~08.90	2000	Z20S	PGF22	RN1893V	PN2204		FN1146
11.86~01.92	2700	TD27	AF22	RN1893V	PN2204		FN1146
01.92~08.97	2700	TD27	P_F23	RN1893V RN1333V RN1088V	PN2204 PN2344 PN2105	DN1296 DN1303	FN1163 FN1174 FN1179 FN2280
08.97~06.07	3200	QD32	R4F23	RN1893V	PN2204		FN1163 FN1179 FN2280

NISSAN » Cabstar

07.92~12.95	2500	TD25	F23	RN1893V	PN2204	DN1303	FN1163
10.97~01.11	3200	QD32	F23	RN1088V RN1893V	PN2344 PN2204	DN1303	FN1163
