ROTOR DISC » RN1878V

Specification

Type
Vented
Outter Ø
280
Num. of holes
5
Disc Thickness (Max)
24
Height
44
Centering Diameter
61
Pitch Circle Ø
108
Disc Thickness (Min)
21.8
Drum Ø:
139
Structure Material
G3000

Cross Reference

Daimler AG
A4154200001
MERCEDES-BENZ
A 415 420 07 01
NISSAN
40206-00Q2G
NISSAN
40206-00Q2L
RENAULT
40 20 642 30R
RENAULT
77 01 209 839
RENAULT
82 01 464 604
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.12~08.21 1500 OM 607.951 W415 RN1878VRN2142V PN2800PN0532 RN1884H FN43551PN0533
11.12~08.21 1500 OM 607.951 W415 RN1878VRN2414V PN0532 RN1884H PN0533
11.12~08.21 1500 OM 607.951 W415 RN1878V PN0532 RN1884H PN0533
07.19~ 1500 K9K X61 RN1878V PN0532W RN1884H PN0533
01.09~01.21 1500 K9K 608 FW07 RN1878V PN0532 DN1322HRN1884H FN43551PN0533
01.09~03.18 1500 K9K 608 FW08 RN1878VRN2414V PN0532PN2800PN9805 RN1884H FN43551PN0533
02.08~02.18 1500 K9K 800 FW0A RN1878VRN2414V PN2800PN0532 RN1884HDN1322H FN43551PN0533
12.09~05.13 1500 K9K 808 KW05 RN1878VRN2414V PN0532 RN1884H PN0533
03.13~11.20 1500 K9K 812 FW0 VAN LCV LHD RN1878V PN0532 RN1884H PN0533FN43551
03.19~ 1500 K9K 872 FW16 RN1878VRN2414V PN0532 FN43551PN0533
03.19~ 1500 K9K 872 VAN LCV RHD RN1878VRN2414V PN0532 RN1884H FN43551PN0533
02.08~02.18 1600 K4M 831 FW0D RN1878V PN0532PN2800 RN1884HDN1322H FN43551PN0533
10.07~01.21 1600 K4M 831 KW0D RN2414VRN1878V PN0532PN9805PN2800 DN1322HRN1884H PN0533FN43551
01.09~01.21 1600 K4M 835 FW0U RN1878V PN0532 RN1884H FN43551PN0533
01.09~02.21 1600 K4M 835 KW0U RN1878V PN0532 RN1884H PN0533FN43551
01.12~01.21 1600 K4M 835 KW0U RN2414VRN1878V PN0532 RN1884H FN43551PN0533
09.02~09.09 2000 M9R 7# BM1K RN1878V PN0204 RN1878V PN0019W

Exemption from liability: the catalog data is advisory and can be used for reference only
