ROTOR DISC » RN1661V
Specification
Type
Vented
Outter Ø
276
Num. of holes
5/9
Disc Thickness (Max)
24
Height
49.6
Centering Diameter
65
Pitch Circle Ø
112
Front/Rear
Front
Drum Ø:
144
Disc Thickness (Min)
21
Structure Material
G3000
Hole Ø:
15.3
Cross Reference
FAW-VW
L 5QD 615 301 F
SAIC VOLKSWAGEN
5QD 615 301 F
VAG
5Q0 615 301 A
VAG
5Q0 615 301 E
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 02.13~10.20 | 1200 | CJZA | HB / SDN / SB | RN1374VRN1661V | PN0699WPN33005W | RN33004 | PN33003 | |
| 05.12~10.20 | 1200 | CYVB | HB / SDN / SB | RN1374VRN1661VRN1377V | PN33005WPN0699W | RN1739VRN33004 | PN33003 | |
| 04.12~10.20 | 1600 | CRKB | HB / SDN / CABR | RN1377VRN1661VRN1374V | PN33005WPN0699W | RN33004RN1739V | PN33003 |
| 05.15~08.20 | 1000 | CHZD | 5F__4_ | RN1661V | PN0699W | RN33004 | PN33003 | |
| 10.13~08.20 | 1200 | CYVB | 5F__W_ | RN1661V | PN0891 | RN33005 | PN0019W |
| 11.16~08.20 | 1000 | CHZC | BQ1_A_ | RN1661V | PN0699W | RN33004 | PN33003 | |
| 11.12~03.17 | 1200 | CJZA | 5G12DZ | RN1661VRN1374VRN1377V | PN33005WPN0699W | RN33004RN1739VRN1735 | PN33003 | |
| 08.12~03.17 | 1200 | CJZB | 5G1_CV | RN1661VRN1377VRN1374V | PN0699WPN33005W | RN1735RN33004RN1739V | PN33003 | |
| 05.14~03.17 | 1200 | CYVB | 5G1_B_ | RN1661V | PN0699W | RN33004 | PN33003 | |
| 08.12~03.17 | 1400 | CHPA | 5G14JZ | RN1377VRN1374VRN1661V | PN33005WPN0699W | RN1735RN1739VRN33004 | PN33003 | |
| 11.12~05.13 | 1400 | CMBA | 5G1_Z_ | RN1374VRN1377VRN1661V | PN0699WPN33005W | RN33004RN1735 | PN33003 | |
| 02.12~08.20 | 1400 | CPTA | 5G1 | RN1661V | PN33005W | RN33004 | ||
| 11.12~03.17 | 1400 | CXSA | 5G1_G_ | RN1377VRN1374VRN1554VRN1661V | PN0699WPN0559WPN33005W | RN1735RN33004RN1739V | PN33003 |
