NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1658

ROTOR DISC » RN1658

Specification

Type

Solid

Outter Ø

289.7

Num. of holes

5

Disc Thickness (Max)

10

Height

45.9

Centering Diameter

108.3

Front/Rear

Front

Pitch Circle Ø

139.7

Drum Ø:

183

Disc Thickness (Min)

8

Structure Material

G3000

Cross Reference

SUZUKI

5521176J00

SUZUKI

5521176J01

SUZUKI

5521176J02

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

SUZUKI » Jimny

10.98~	660	K6A	JB23W	RN1658 RN1038	PN9118	DN1405	FN5524
07.12~05.19	1300	M13A	JB4# LHD	RN1038 RN1658	PN9118	DN1405	FN5524
10.98~07.12	1300	M13A	JB43V RHD	RN1658 RN1038	PN9118	DN1405	FN5524
07.12~05.19	1300	M13A	JB43V RHD	RN1658	PN9118	DN1405	FN5524
03.18~	1500	K15B	JB74V LHD	RN1658	PN9816		FN5524
03.18~	1500	K15B	JB74V RHD	RN1658	PN9816		FN5524
01.20~	1500	K15B	JB74V RHD	RN1658	PN9816		FN5524

SUZUKI » Jimny Sierra

07.18~

1500

K15B

3BA-JB74W

RN1658

PN9816

FN5524
