ROTOR DISC » RN1617V

Specification

Type
Vented
Outter Ø
296
Num. of holes
5
Disc Thickness (Max)
28
Height
49.2
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Front
Drum Ø:
144
Disc Thickness (Min)
25
Structure Material
G3000

Cross Reference

TOYOTA
43512-28190
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.20~ 2500 2AR-FXE AYH36R RN1617V PN1527 RN1968V PN1852
01.20~ 3500 2GR-FE GGH31 RN1617V PN1527 RN1968V PN1852
04.08~01.15 2400 2AZ-FE ANH20R RN1617V PN1527 RN1670 PN1239 FN0567
04.08~01.15 2400 2AZ-FE ANH20W RN1617VRN1443V PN1845PN1527 RN1670 PN1239 FN0567
04.08~01.15 2400 2AZ-FE ANH25W RN1617V PN1527 RN1670 PN1239 FN0567
11.11~01.15 2400 2AZ-FXE ATH20W RN1617V PN1527 RN1670 PN1239 FN0567
01.15~ 2500 2AR-FE AGH30R RN1617V PN1527 RN1968V PN1852
01.15~ 2500 2AR-FE AGH30W RN1617V PN1527 RN1968V PN1852
01.15~ 2500 2AR-FE AGH35W RN1617V PN1527 RN1968V PN1852
01.15~06.23 2500 2AR-FXE AYH30W RN1617V PN1527 RN1968V PN1852
06.10~01.15 3500 2GR-FE GGH20L RN1617V PN1527 RN1670 PN1239 FN0567
04.08~01.15 3500 2GR-FE GGH20W RN1617V PN1527 RN1670 PN1239 FN0567
04.08~01.15 3500 2GR-FE GGH25W RN1617V PN1527 RN1670 PN1239 FN0567
01.15~ 3500 2GR-FE GGH30W RN1617V PN1527 RN1968V PN1852
01.15~ 3500 2GR-FE GGH35W RN1617V PN1527 RN1968V PN1852
01.06~12.08 2400 2AZ-FE ACR55W RN1617V PN1527 RN1616 PN1239 FN0567
01.06~10.19 2400 2AZ-FE ACR50W RN1617V PN1527 RN1616 PN1239 FN0567
06.06~10.19 2400 2AZ-FXE AHR20W RN1617V PN1527 RN1616 PN1239
01.06~05.16 3500 2GR-FE GSR50W RN1617V PN1527 RN1616 PN1239 FN0567
01.06~12.08 3500 2GR-FE GSR55W RN1617V PN1527 RN1616 PN1239 FN0567
01.06~10.19 2400 2AZ-FE ACR50L RN1617V PN1527 RN1616 PN1239 FN0567
01.06~ 2400 2AZ-FE ACR50R RN1617V PN1527 RN1616 PN1239 FN0567
11.06~10.19 3500 2GR-FE GSR50L RN1617V PN1527 RN1616 PN1239 FN0567
11.06~01.18 3500 2GR-FE GSR50R RN1617V PN1527 RN1616 PN1239 FN0567
01.06~ 2400 2AZ-FE ACR50L RN1617V PN1527 RN1616 PN1239
01.06~ 2400 2AZ-FE ACR50R RN1617V PN1527 RN1616 PN1239 FN0567

Exemption from liability: the catalog data is advisory and can be used for reference only
