ROTOR DISC » RN1603

RN1603

Specification

Type
Solid
Outter Ø
304.9
Num. of holes
5
Disc Thickness (Max)
10
Height
61
Centering Diameter
64.2
Pitch Circle Ø
114.3
Front/Rear
Rear
Drum Ø:
200
Structure Material
G3000
Disc Thickness (Min)
8.5

Cross Reference

GREAT WALL
3502012XKZ16A
HAVAL
3502012XKZ16A
HONDA
42510-SFJ-W00
HONDA
42510-SLG-W00
HONDA
42510-T0T-H01
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

ACURA   »   CDX

05.16~ 1500 L15B9 RH4 RN2227V PN0647 RN1603 PN8807 FN8003

HONDA   »   CR-V

09.06~09.09 2400 K24Z RE4 CHN LHD RN1415V PN8802 RN1603 PN8807 FN8003
