ROTOR DISC » RN1566V
Specification
Type
Vented
Outter Ø
295
Num. of holes
5
Disc Thickness (Max)
25
Height
51.5
Centering Diameter
68
Pitch Circle Ø
114.3
Drum Ø:
142.2
Disc Thickness (Min)
23
Structure Material
G3000
Cross Reference
MAZDA
B45G33251A
MAZDA
BJT233251A
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 02.16~ | 1500 | S5# | DK# | RN1566V | PN25005 | RN2236 | PN25001 | |
| 02.15~ | 1500 | S5-DPT# | AEDS01 | RN1566V | PN25005 | RN2236 | PN25001 | |
| 02.15~ | 1500 | S5-DPT# | DK5AW | RN1566V | PN25005 | RN2236 | PN25001 | |
| 02.15~ | 1500 | S5-DPT# | DK5FW JPN | RN1566V | PN25005 | RN2236 | PN25001 | |
| 05.18~ | 1800 | S8-DPT# | 3DA-DK8FW | RN1566V | PN25005 | RN1565 | PN5819 | |
| 02.18~ | 1800 | S8-Y1 | DK6W | RN1566V | PN25005 | RN1565 | PN5819 | |
| 02.15~ | 2000 | PE-VPS | AEDS01 | RN1566V | PN25005 | RN2236 | PN25001 | |
| 02.18~ | 2000 | PE-VPS | AEDS03 DK6W | RN1566V | PN25005 | RN1565 | PN5819 | |
| 07.17~ | 2000 | PE-VPS | DKEAW | RN1566V | PN25005 | RN2236 | PN25001 | |
| 02.16~ | 2000 | PE-VPS | DKEFW | RN1566V | PN25005 | RN2236 | PN25001 | |
| 05.15~ | 2000 | PEX3 | DK4W7 | RN1566V | PN25005 | RN2236 | PN25001 | |
| 02.15~ | 2000 | PEX3 | JM6DK2W | RN1566V | PN25005 | RN2236 | PN25001 |
| 05.16~11.18 | 1500 | S5 | BM# | RN1566V | PN25005 | RN1565 | PN5819 | |
| 05.16~02.19 | 2000 | PE | ABBA15 SDN | RN1566V | PN25005 | RN1565 | PN25004PN5819 | |
| 05.16~11.18 | 2000 | PE | ALBA16 SDN JM7 | RN1566V | PN25005 | RN1565 | PN5819 | |
| 05.16~02.19 | 2000 | PE | SDN 3MZ US | RN1566V | PN25005PN5815 | RN1565 | PN5819 | |
| 06.13~08.16 | 2000 | PE-# | BM HB | RN1566V | PN25005 | RN1565 | PN5819PN25004 | |
| 06.13~08.16 | 2000 | PE-VPH | ALBA15 SDN GL | RN1566V | PN25005 | RN1565 | PN25004 | |
| 02.14~08.16 | 2000 | PE-VPH | ALBAM1 SDN GL | RN1566V | PN5815 | RN1565 | PN25003 | |
| 06.13~08.16 | 2000 | PE-VPH | BM SDN | RN1566V | PN25005 | RN1565 | PN25004 | |
| 01.13~08.16 | 2000 | PE-VPS | BM US | RN1564VRN1566V | PN25005 | RN1565 | PN25004 | |
| 01.14~ | 2000 | PE-Y# | BM/BN SDN VTN | RN1566V | PN25005 | RN1565 | PN5819PN25004 | |
| 05.16~ | 2200 | SH | BM | RN1566V | PN25005 | RN1565 | PN25004 | |
| 01.13~08.16 | 2200 | SH-VPTS | BM | RN1566V | PN25005 | RN1565 | PN25004 | |
| 05.16~02.19 | 2500 | PY-VPS | ABBA15 SDN | RN1566V | PN25005 | RN1565 | PN5819PN25004 | |
| 08.16~02.19 | 2500 | PY-VPS | SDN US | RN1566V | PN5815PN25005 | RN1565 | PN5819 |
