ROTOR DISC » RN43008V

Specification

Outter Ø
269
Num. of holes
5
Disc Thickness (Max)
22.5
Height
44.3
Centering Diameter
68
Pitch Circle Ø
114.3
Front/Rear
Front
Type
Vented
Drum Ø:
141
Disc Thickness (Min)
19.8
Structure Material
G3000

Cross Reference

NISSAN
40206-00Q0M
NISSAN
40206-00Q1A
RENAULT
40 20 617 15R
RENAULT
40 20 663 00R
RENAULT
82 01 703 977
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.15~01.18 1600 H4M738 HSAV RN43008V PN2800 DN1596H FN43551
01.17~06.21 1600 H4M 736 H5JH RN43008V PN2800 DN1596H FN43551
01.10~06.15 1500 K9K HSM5 RHD IND RN43007VRN43008V PN2800PN0551 DN1596H FN43551
01.10~06.15 1500 K9K 886 HSM3 RHD IND RN43008VRN43007V PN2800 DN1596H FN43551
06.15~07.21 1600 H4M438 HSRGA RN43008V PN2800 DN1596H FN43551
06.17~ 1600 H4M738 HJD2 CHL RN43007VRN43008V PN0551PN2800 DN1596H FN43551
07.19~ 1600 H4M738 HMM1 RN43008V PN9805 DN1596H FN43551
06.15~07.21 1600 H4M751 HSJA RN43008V PN2800 DN1596H FN43551
01.10~06.15 1600 K4M HSA8 RN43007VRN43008V PN2800PN9805 DN1625DN1596H FN0673FN43551
01.12~06.15 2000 F4R40# HSMJ RUS RN43008VRN43007V PN2800PN0551 DN1625DN1596H FN0673FN43551
01.12~01.18 2000 F4R403 HSMJ RN43008VRN43007V PN2800PN0551 DN1625DN1596H FN0673FN43551
04.15~01.18 2000 F4R410 HSAG RN43007VRN43008V PN2800PN0551 DN1625DN1596H FN0673FN43551
04.15~01.18 2000 F4R412 HSAB RN43008VRN43007V PN0551PN2800 DN1596H FN43551FN0673
04.16~ 1600 H4M H5JA RN43008V PN2800 DN1596H FN43551

Exemption from liability: the catalog data is advisory and can be used for reference only
