BRAKE PADS » PN43001

Specification

Length-1
140
Width-1
40
Thickness-1
17.3
Length-2
140
Width-2
42
Thickness-2
17.3
Pcs In Set
4
Brake System
Ate - Teves

Cross Reference

FMSI
D1830-9140
MERCEDES-BENZ
A 453 421 11 00
RENAULT
41 06 023 96R
RENAULT
41 06 025 81R
RENAULT
41 06 056 12R
RENAULT
41 06 096 46R
SMART
453 421 00 00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.12~03.19 900 H4B BH__ RN1571V PN9805PN43001PN2800 DN1599HDN1322H FN0619FN43551
11.12~06.15 1200 D4F 740 B98 HB LHD RN1571V PN2800PN43001PN9805 DN1599H FN43551FN0619
11.12~03.19 1500 K9K 608 BHAL RN1571V PN43001 DN1322H FN0619
11.12~03.19 1500 K9K 612 BHM4 RN2142V PN43001 DN1599H FN0619
11.12~04.15 1500 K9K 628 BHAH RN2142VRN1571V PN9805PN43001PN0773 DN1322HDN1599H FN43551FN0619
03.13~11.16 1500 K9K 612 L8M4 RN1571V PN43001 DN1322H FN0619
11.16~ 1500 K9K612 L8AL RN1571V PN43001PN0773 DN1627H FN0619
03.14~ 1600 K4M842 L8MT RN1571V PN43001 FN43551FN0619
05.17~ 1600 K7M812 L8JB LHD RN1571VRN1191 PN43001 DN1627H FN0619
11.12~ 900 H4B400 B8MA RN1571V PN43001 DN1627H FN0619
09.14~ 900 H4B4 BCM RN1571V PN43001 DN1605 FN0724
09.14~ 1000 H4D4 BCM RN1571V PN43001 DN1605 FN0724
09.14~ 1000 M 281.920 453.342 RN1571V PN43001 DN1601 FN0778

Exemption from liability: the catalog data is advisory and can be used for reference only
