ROTOR DISC » RN2293V

Specification

Type
Vented
Outter Ø
320
Num. of holes
5
Hole Ø:
14.5
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
49.1
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Front
Structure Material
G3000
Drum Ø:
168

Cross Reference

GEELY
4048008100
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.19~ 1800 JLE-4G18TD NL3 RN2293V PN8019 RN2294 PN0538
02.18~ 2000 JLD-4G20 NL3 RN2293V PN8019 RN2294 PN0538
02.18~ 2400 JLD-4G24 NL3 RN2293V PN8019 RN2294 PN0538
01.19~ 1800 4G18TD RN2293V

Exemption from liability: the catalog data is advisory and can be used for reference only
