ROTOR DISC » RN2288V

Specification

Type
Vented
Outter Ø
318
Num. of holes
5
Hole Ø:
15.3
Disc Thickness (Max)
30
Disc Thickness (Min)
28
Height
57.2
Centering Diameter
68
Pitch Circle Ø
112
Drum Ø:
149.5
Front/Rear
Front
Structure Material
G3000

Cross Reference

VAG
80A 615 301
VAG
80A 615 301 E
VAG
8W0 615 301 AA
VAG
8W0 615 301 H
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.15~08.18 3000 CSWB SDN / EST RN2288VRN33003VRN2118V PN0728PN0732W RN2059RN1734V PN0697
11.16~ 1400 CVNA COUPE / LB / CABR RN2288VRN2195VRN2118V PN0732WPN0728 RN1734VRN2059 PN0697
01.17~ 2000 CZHA COUPE / LB / CABR RN2118VRN2288V PN0728PN0732W RN2059 PN0697
06.16~ 2000 DESA COUPE / LB / CABR RN2288VRN33003VRN2195VRN2118V PN0732WPN0728 RN1734VRN2059 PN0697
06.16~ 2000 DETA COUPE / LB / CABR RN2118VRN2288V PN0728PN0732W RN2059 PN0697
05.20~ 2000 DMSA COUPE / LB / CABR RN2288VRN2195VRN2118V PN0732WPN0728 RN1734VRN2059 PN0697
09.18~ 2000 DFBA 4KA0I_ RN2288V PN0728 RN2059 PN0697
10.18~ 2000 DKNA SB SPORTBACK RN2118VRN2288V PN0728 RN2059RN1734VRN2187V PN0688PN0697

Exemption from liability: the catalog data is advisory and can be used for reference only
