ROTOR DISC » RN2191V

RN2191V

Specification

Type
Vented
Outter Ø
256
Num. of holes
4
Disc Thickness (Max)
22
Disc Thickness (Min)
19
Height
36.6
Centering Diameter
65
Pitch Circle Ø
100
Drum Ø:
132
Structure Material
G3000
Front/Rear
Front
Hole Ø:
13.8

Cross Reference

SEAT
1S0615301
VAG
1S0 615 301 F
VAG
1S0 615 301 H
VAG
1S0 615 301 J
VAG
1S0 615 301 L
VAG
1S0 615 301 M
VAG
5U0 615 301 E
VAG
JZW 698 302 CD
VOLKSWAGEN
1S0615301L
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SKODA   »   Citigo

01.20~ 61 EBMA 5DR HB RN2191V PN0148W DN1529 FN0534
10.11~08.19 1000 CHYB RN2191V PN0148W DN1529 FN0534

VOLKSWAGEN   »   Gol

10.08~01.23 1600 CCRA 5U RN2188VRN2189VRN2191V PN33010PN0113WPN33017 DN1522 FN0796FN0534
12.15~12.23 1600 CFZA 5U5 RN2191V PN0148W FN0796
04.19~01.23 1600 CWSA 5U RN2191VRN2188V PN33010PN0148W FN0796

VOLKSWAGEN   »   UP

07.16~ 61 EBMA 5DR HB RN2191V PN0148W DN1529 FN0534

VOLKSWAGEN   »   Voyage

01.16~01.23 1600 CFZA 5U__F_ RN2191V PN0148W FN0796
