ROTOR DISC » RN29001V

RN29001V

Specification

Type
Vented
Outter Ø
272
Num. of holes
4
Disc Thickness (Max)
22
Height
40
Centering Diameter
60
Front/Rear
Front
Pitch Circle Ø
100
Drum Ø:
150
Disc Thickness (Min)
20
Structure Material
G3000

Cross Reference

SUZUKI
55311-68L50
SUZUKI
55311-71L50
SUZUKI
55311-71L51
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   Swift IV

09.10~11.16 1200 K12B ZC72S JPN RN29001VRN2245V PN9529 RN1955DN1369 FN9991PN9808
10.09~03.13 1200 K12B ZC72S LHD RN29001V PN5562 RN1955DN1369 FN9991PN9808
03.13~02.17 1200 K12B ZC72S LHD RN29001V PN5562 RN1955DN1369 FN9991PN9808
09.10~01.17 1200 K12B ZD72S JPN RN29001V PN5562 RN1955 PN9808
03.10~ 1400 K14B AZG414 RN29001V PN5562 DN1369RN1955RN1693 FN9991PN9808
03.10~ 1400 K14B ZC82S LHD RN29001VRN2245V PN5562PN9529 DN1369RN1955RN1693 FN9991PN9808
03.10~03.13 1400 K14B ZC82S RHD RN29001V PN5562 DN1369RN1693RN1955 FN9991PN9808
03.13~02.17 1400 K14B ZC82S RHD RN29001VRN2245V PN5562PN9529 DN1369RN1955RN1693 PN9808FN9991

SUZUKI   »   Swift V

12.16~ 1200 K12B ZC53S RN29001V PN5544 RN1955 PN9808
