ROTOR DISC » RN31002

Specification

Type
Solid
Outter Ø
278
Num. of holes
5
Disc Thickness (Max)
9
Height
57.5
Centering Diameter
67
Pitch Circle Ø
112
Front/Rear
Rear
Drum Ø:
164
Disc Thickness (Min)
7.3
Structure Material
G3000

Cross Reference

MERCEDES-BENZ
204 423 05 12
MERCEDES-BENZ
A 000 423 13 12
MERCEDES-BENZ
A 000 423 13 12 07
MERCEDES-BENZ
A2044230512
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.12~01.14 1600 M 274.910 W204 RN1794DSETRN31001V PN0452W RN1708RN31002 PN0460W FN0672
11.09~01.14 1800 M 271.820 W204 RN1794DSETRN31001V PN0452W RN31002 PN0460W FN0672
09.07~ 1800 M 271.952 C204 RN31001V PN0452W RN31002 PN0460W
08.07~08.14 1800 M 271.952 S204 RN1794DSETRN31001V PN0452W RN1708RN31002 PN0460W FN0672
01.07~12.09 1800 M 271.952 W204 RN1463VRN31001VRN1794DSET PN0452W RN1708RN31002 PN0460W FN0672
04.10~01.14 2200 OM 651.913 W204 RN1794DSETRN31001V PN0452W RN1708RN31002 PN0460W FN0672
01.08~06.11 1600 M 271.910 W204 RN31001VRN1794DSET PN0452W RN1708RN31002 PN0460W FN0672
01.07~12.09 1800 M 271.952 W204 RN31001VRN1794DSET PN0452W RN31002RN1708 PN0460W FN0672
08.07~ 2200 OM 646.811 C204 RN31001V PN0452W RN31002 PN0460W FN0672
08.07~12.09 2200 OM 646.811 S204 RN31001V PN0452W RN31002 PN0460W FN0672
03.11~01.15 2200 OM 651.913 W204 RN31001V PN0452W RN31002RN1708 PN0460W FN0672
01.07~12.09 2100 OM 646.811 W204 RN31001VRN1794DSET PN0452W RN31002RN1708 PN0460W FN0672
08.07~01.14 2300 M 272.921 C204 RN31001V PN0452W RN31002 PN0460W FN0672

Exemption from liability: the catalog data is advisory and can be used for reference only
