DRUM BRAKE » DN1607

DN1607

Specification

Outter Ø
208
Num. of holes
4
Centering Diameter
53.5
Height
83
Pitch Circle Ø
100
Drum Ø
180
Structure Material
G3000
Hole Ø
M12x1,5
Notes
w/o Wheel Bearing, w/o ABS Speed Sensor

Cross Reference

RENAULT
60 01 548 126
RENAULT
77 00 419 824
RENAULT
77 00 752 363
RENAULT
77 00 783 030
RENAULT
77 01 463 277
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

RENAULT   »   Clio II

09.98~06.01 1200 D7F720 BB0A 5DR HB RN1000RN1037VRN1002V PN0284W DN1609HDN1607 FN0619FN0778FN0602

RENAULT   »   Logan

08.04~06.15 1400 K7J710 LS0A RN1191RN1000RN1037VRN1571V PN0284W DN1607DN1609 FN0556FN0619
01.05~12.07 1400 K7J710 LS0G RN1191RN1000RN1037VRN1571V PN0284W DN1607DN1609 FN0556FN0619FN0602
09.09~12.14 1400 K7J710 LS12 RN1000RN1037VRN1571VRN1191 PN0284W DN1607 FN0556FN0602FN0619
01.08~08.09 1600 K7M710 LS0B RN1571VRN1191RN1000RN1037V PN0284W DN1607 FN0619FN0556FN0602
09.09~12.14 1600 K7M710 LS11 RN1000RN1571VRN1191 PN0284W DN1607 FN0619FN0556FN0602

RENAULT   »   R 5 II

10.85~12.96 1400 C3J7# B407 RN1000 PN0284W DN1607 FN0524

RENAULT   »   Twingo

03.93~10.96 1200 C3G 70# C06 RN1001 PN0240 DN1607 FN0521
