DRUM BRAKE » DN1577

DN1577

Specification

Outter Ø
335
Num. of holes
6
Hole Ø
12.4
Centering Diameter
96.5
Height
80.7
Pitch Circle Ø
139.7
Drum Ø
295
Structure Material
G3000

Cross Reference

GM
97113020
ISUZU
8-97113-020-0
ISUZU
8-97910-577-1
OPEL
05 68 064
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

ISUZU   »   Pickup TFR

01.99~12.03 2800 4JB1 TFS55 LHD RN1326V PN4196 DN1577 FN4462FNP4462
01.99~12.03 2800 4JB1 TFS55 RHD RN1326V PN4196 DN1577 FNP4462FN4462

OPEL   »   Campo

07.94~12.01 2500 4JA1T TFS PN4196 DN1577 FN4452

OPEL (Vauxhall)   »   Brava

10.96~07.01 2500 25D TFS54 PN4196 DN1577
10.96~07.01 2500 25D TFS56 PN4196 DN1577
