DRUM BRAKE » DN1463

Specification

Outter Ø
272
Num. of holes
4
Hole Ø
12.8
Centering Diameter
90.2
Height
63.3
Pitch Circle Ø
114.3
Drum Ø
228.6
Structure Material
G3000

Cross Reference

BENDIX
PDR0663
HYUNDAI
58411-34000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.96~08.98 1800 G4CN Y3 PN2245 DN1463 FN1879PN8210
05.93~08.98 2000 G4CP Y3 PN2245 DN1463 PN8210FN1879

Exemption from liability: the catalog data is advisory and can be used for reference only
