DRUM BRAKE » DN1429

Specification

Outter Ø
196
Num. of holes
4
Hole Ø
13.8
Centering Diameter
39.9-46
Height
70.5
Pitch Circle Ø
139,7
Drum Ø
165
Structure Material
G3000

Cross Reference

DAIHATSU
42403-87217-000
DAIHATSU
42403-87222-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.95~12.98 800 ED20 L501 RN2487 PN6451 DN1429 FN0024
01.90~01.95 850 ED# L201 LHD PN6451 DN1429 FN0027
01.90~01.95 850 ED# L201 RHD RN2487 PN6114PN6451 DN1429 FN0027
08.95~09.98 660 JB-JL L602S RN2487 PN6295PN6451 DN1429 FN0027
08.95~09.98 850 ED# L601 RN2487 PN6451 DN1429 FN0024

Exemption from liability: the catalog data is advisory and can be used for reference only
