DRUM BRAKE » DN1403

Specification

Outter Ø
306
Num. of holes
5
Hole Ø
13
Centering Diameter
58
Height
70.7
Pitch Circle Ø
100
Drum Ø
254
Structure Material
G3000

Cross Reference

SUBARU
26740-FG000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.07~06.12 1500 EL154 GE2 JPN RN1091V PN7493 DN1403 FN7757
03.07~12.11 1500 EL154 GH2 RN1091VRN1010V PN7493PN7460 DN1403RN1529 PN7501FN7757 FN0625
03.07~12.11 1500 EL154 GH3 JPN RN1091V PN7493 DN1403 FN7757
03.07~12.11 1500 EL154 GH3# LHD RN1091VRN1010V PN7493PN7460 DN1403RN1529 PN7501FN7757 FN0625
03.07~12.11 1500 EL154 GH3# RHD RN1010VRN1091V PN7460PN7493 RN1529DN1403 FN7757PN7501 FN0625

Exemption from liability: the catalog data is advisory and can be used for reference only
