DRUM BRAKE » DN1208

DN1208

Specification

Outter Ø
252
Num. of holes
5
Hole Ø
14.5
Centering Diameter
55
Height
53.3
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

TOYOTA
42431-20450
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Allion

05.07~09.15 1500 1NZ-FE NZT260 RN2074VRN1576V PN1508PN1524 DN1208 FN2383
04.10~03.21 1800 2ZR-FAE ZRT260 RN1576V PN1524 DN1208 FN2383
05.07~10.10 1800 2ZR-FE ZRT260 RN1576V PN1524 DN1208 FN2383

TOYOTA   »   Prius

08.03~12.11 1500 1NZ-FXE NHW20 RN1541V PN1472 DN1208DN1233 FN2342FN2403 FN0614
08.03~12.11 1500 1NZ-FXE NHW20 RN1541V PN1472 DN1208DN1233 FN2403FN2342 FN0614
08.03~12.11 1500 1NZ-FXE NHW20L RN1541V PN1472 DN1233DN1208RN1440 PN1431PN1454FN2342 FN0614
08.03~12.11 1500 1NZ-FXE NHW20R RN1541V PN1472 DN1233RN1440DN1208 FN2342PN1431 FN0614
