ROTOR DISC » RN1527V
Specification
Type
Vented
Disc Thickness (Max)
30
Num. of holes
5
Height
57
Centering Diameter
58
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
316
Drum Ø:
148.7
Disc Thickness (Min)
28
Structure Material
G3000
Hole Ø:
13
Cross Reference
SUBARU
26300-AL010
SUBARU
26300-AL03A
SUBARU
26300-AL04A
SUBARU
26300-FG000
SUBARU
26300-XA00A
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.04~01.14 | 3000 | EZ30 | WXE RHD | RN1527V | PN7499 | RN1528V | PN7803 | FN0651 |
| 04.04~07.07 | 3000 | EZ30D | WX85 LHD US | RN1527V | PN7499 | RN1528V | PN7803 | FN0651 |
| 03.06~01.14 | 3000 | EZ30D | WXE LHD EU | RN1527V | PN7499 | RN1528V | PN7803 | FN0651 |
| 04.07~01.14 | 3600 | EZ36D | WX EA LHD EU | RN1527V | PN7499 | RN1528V | PN7803 | FN0651 |
| 04.07~01.14 | 3600 | EZ36D | WX KS LHD GCC | RN1527V | PN7499 | RN1528V | PN7803 | FN0651 |
| 04.07~01.14 | 3600 | EZ36D | WXF KA RHD | RN1527V | PN7499 | RN1528V | PN7803 | FN0651 |
| 03.13~ | 2000 | FA20E | VAG | RN1527V | PN7499 | RN2727 | PN7501 | FN0755 |
| 03.16~11.21 | 2000 | FA20F | VA1A US | RN1527V | PN7499 | RN2727 | PN7501 | FN0755 |
| 05.12~10.14 | 2500 | EJ25 | GJ9 | RN1527VRN1122V | PN7463 |
| 03.07~01.14 | 2500 | EJ257 | GRF | RN1527VRN1477V | PN0150SPN7499 | RN2167VRN2448V | PN0226S | FN0625 |
| 07.07~02.14 | 2500 | EJ257 | GRF | RN1527VRN1477V | PN7499PN0150S | RN2448VRN2167V | PN0226S | FN0625 |
| 07.10~08.14 | 2500 | EJ257 | GVF | RN1527VRN1477V | PN0150SPN7499 | RN2448VRN2167V | PN7803PN0226S | FN0625 |
| 03.15~08.20 | 2000 | EE20Z | BS | RN1527V | PN7499 | RN1691V | PN7804 | |
| 08.14~09.21 | 2500 | FB25A | BS9 JPN | RN1527V | PN7499 | RN1691V | PN7804 | |
| 08.14~08.20 | 2500 | FB25A | BS9K RHD | RN1527V | PN7499 | RN1691V | PN7804 | |
| 08.14~08.20 | 2500 | FB25A | BS9L LHD | RN1527V | PN7499 | RN1691V | PN7804 | |
| 08.14~10.17 | 2500 | FB25B | BSBHC US | RN1527V | PN7499 | RN1691V | PN7804 | |
| 08.14~08.20 | 3600 | EZ36D | BSF | RN1527V | PN7499 | RN1691V | PN7804 |
| 12.13~08.20 | 1600 | FB16E | VM4 JPN | RN1527V | PN7499 | RN1691V | PN7804 | |
| 06.14~06.20 | 1600 | FB16E | VM4BK25 | RN1527V | PN7499 | RN1691V | PN7804 | |
| 04.17~06.20 | 1600 | FB16E | VM4DK15 RHD | RN1527V | PN7499 | RN1691V | PN7804 | |
| 12.13~08.17 | 1600 | FB16F | VM4CL25 LHD | RN1527V | PN7499 | RN1691V | PN7804 | |
| 06.14~06.20 | 2000 | FA20E | VMG | RN1527V | PN7499 | RN1691V | PN7804 |
