ROTOR DISC » RN1501V
Specification
Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
48.3
Centering Diameter
72
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
295.7
Drum Ø:
142.8
Disc Thickness (Min)
26
Structure Material
G3000
Cross Reference
MAZDA
L206-33-25XA
MAZDA
L2063325X
MAZDA
L2143325X
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 05.07~06.09 | 2300 | L3# | AEES01 EU JMZER | RN1503VRN1501V | PN3813 | RN1502V | PN5814 | FN0696 |
| 06.09~01.13 | 2300 | L3-VDT | AEES02 EU JMZER | RN1501V | PN3813 | RN1502V | PN5814 | FN0696 |
| 02.06~01.15 | 2300 | L3-VDT | AUES01 US JM3ER | RN1501V | PN3813 | RN1502V | PN5814 | FN0696 |
| 01.06~01.15 | 2300 | L3-VDT | EG52 JM0ER | RN1501V | PN3813 | RN1502V | PN5814 | FN0696 |
| 01.07~01.15 | 2300 | L3-VDT | ER3P | RN1501V | PN3813 | RN1502V | PN5814 | FN0696 |
| 04.09~01.15 | 2500 | L5 | ER | RN1501V | PN3813 | RN1502V | PN5814 | FN0696 |
| 08.09~01.15 | 2500 | L5 | ER19L | RN1501V | PN3813 | RN1502V | PN5814 | FN0696 |
| 06.09~12.12 | 2500 | L5-VE | AEES02 | RN1501V | PN3813 | RN1502V | PN5814 | FN0696 |
