ROTOR DISC » RN2135

Specification

Type
Solid
Outter Ø
298
Num. of holes
6
Disc Thickness (Max)
18
Disc Thickness (Min)
16
Height
71
Centering Diameter
85
Pitch Circle Ø
130
Drum Ø:
180.1
Front/Rear
Rear
Structure Material
G3000
Hole Ø:
15.3

Cross Reference

Daimler AG
A9104230200
Daimler AG
A9104230300
MERCEDES-BENZ
A 910 423 02 00
MERCEDES-BENZ
A 910 423 02 00 07
MERCEDES-BENZ
A 910 423 03 00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.19~ 2000 OM 654.920 907 RN1382V PN0036W RN2135RN2688 PN31025 FN0693
02.18~12.21 3000 OM 642.899 907 RN1382V PN0036W RN2135 PN31025 FN0693
01.18~06.21 2100 M 651.958 907 RN1382V PN0410W RN2135 PN31025 FN0693
05.18~ 2100 OM 651.958 907 RN1382V PN0410W RN2135 PN31025 FN0693
05.18~ 2000 OM 654.920 907 RN1382V PN0410W RN2135 PN31025
05.18~ 3000 OM 642 907,910 RN2135
02.18~ 2100 OM 651.958 910 RN1382V PN0036W RN2135 PN31025 FN0693
02.18~ 2200 OM 651.958 907 RN1382V PN0036W RN2135 PN31025 FN0693
02.18~12.21 3000 OM 642.899 907 RN1382V PN0036W RN2135 PN31025 FN0693

Exemption from liability: the catalog data is advisory and can be used for reference only
