BRAKE SHOE » FN2292

FN2292

Specification

Radius
160
Width
90
Thickness
8.5/11.8
Pcs In Set
4

Cross Reference

AKEBONO
NR-1049
KASHIYAMA
K-2292
TOYOTA
04494-36070
TOYOTA
04494-36170
TOYOTA
04496-36070
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Dyna

09.84~10.89 3400 13B-T BU90 FN2292 FN2292 FN2298
09.84~10.89 3400 13B-T BU95 FN2292 FN2292
02.83~05.95 3400 3B BU41 FN2292 FN2292 FN2298
02.83~05.95 3400 3B BU51 FN2292 FN2292 FN2298
08.88~05.95 3700 14B BU96 FN2292 FN2292 FN2320
01.88~12.95 3700 14B-T BU91 FN2292 FN2292 FN2320
09.84~05.95 4000 1W WU75D FN2292 FN2292 FN2298
09.84~08.97 4000 1W WU90 FN2292 FN2292 FN2298FN2320
09.84~05.95 4000 1W WU95 FN2292 FN2292 FN2320FN2298
