NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1461V

ROTOR DISC » RN1461V

Specification

Type

Vented

Disc Thickness (Max)

25

Num. of holes

5

Height

53

Centering Diameter

62

Front/Rear

Front

Pitch Circle Ø

114.3

Outter Ø

271

Disc Thickness (Min)

23

Drum Ø:

145

Hole Ø:

14.7

Cross Reference

TOYOTA

43512-28090

TOYOTA

43512-28100

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Estima

08.93~12.99

2400

2TZ-FE

TCR10W

RN1461V RN1070V

PN1404 PN1217 PN1273

RN1099V

PN1274

FN0567

TOYOTA » Estima Emina

01.92~08.95	2200	3C-T	CXR20G	RN1532V RN1461V RN1070V	PN1273 PN1404 PN1217	RN1099V DN1256	FN2335 FN2252 PN1274	FN0567
01.92~08.93	2200	3C-T	CXR21G	RN1532V RN1461V	PN1404 PN1217 PN1273	RN1099V	FN2252 FN2335 PN1274	FN0567
01.92~01.95	2400	2TZ-FE	TCR11G	RN1461V RN1070V	PN1217 PN1273 PN1404	RN1099V	FN2335 FN2252 PN1274	FN0567
01.92~01.95	2400	2TZ-FE	TCR20G	RN1532V RN1070V RN1461V	PN1217 PN1273 PN1404	DN1256 RN1099V	PN1274 FN2252 FN2335	FN0567
01.92~01.95	2400	2TZ-FE	TCR21G	RN1070V RN1461V RN1532V	PN1273 PN1217 PN1404	RN1099V	FN2252 FN2335 PN1274	FN0567
05.90~08.94	2400	2TZ-FE	TCR21W	RN1461V	PN1273	RN1099V	PN1274	FN0567
05.90~08.96	2400	2TZ-FZE	TCR11W	RN1461V RN1070V	PN1273 PN1404 PN1217	RN1099V	PN1274	FN0567
08.94~08.96	2400	2TZ-FZE	TCR21W	RN1070V RN1461V	PN1404 PN1217 PN1273	RN1099V	PN1274	FN0567

TOYOTA » Previa

01.90~12.99	2400	2TZ-FE	TCR10L	RN1070V RN1461V RN1532V	PN1273 PN1217	DN1256 RN1099V	FN2335 PN1274 FN2252	FN0567
01.90~12.99	2400	2TZ-FE	TCR20L	RN1070V RN1532V RN1461V	PN1217 PN1404 PN1273	DN1256 RN1099V	FN2252 FN2335 PN1274	FN0567
