ROTOR DISC » RN1451V

RN1451V

Specification

Type
Vented
Disc Thickness (Max)
40
Num. of holes
5
Height
54
Centering Diameter
110
Front/Rear
Front
Pitch Circle Ø
136
Outter Ø
293
Drum Ø:
163
Disc Thickness (Min)
38
Structure Material
G3000

Cross Reference

MITSUBISHI
MC894847
MITSUBISHI
MK584501
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MITSUBISHI   »   Canter

11.10~10.20 3000 4P10-T FBA30 RN1451V PN23001 RN1927V PN23001 FN0655
11.10~10.20 3000 4P10-T FBA50 RN1451V PN23001 RN1927V PN23001 FN0655
10.10~ 3000 4P10-T FEA50 RN1451V PN23001 RN1927V PN23001 FN0655
11.10~ 3000 4P10-T FEB50 RN1451V PN23001 RN1927V PN23001 FN0655
02.98~03.02 3900 4D34 FE639 LHD RN1451V PN3407 RN1927V PN3407 FN4443
04.95~04.04 3900 4D34-T FE649 RN1451VRN2033V FN6653PN3407BL1060 RN1927V FN6653PN3407 FN4443
10.93~04.99 4600 4D35 FE538E RN1451V PN3407 FN6653BL1060 FN4443
02.04~03.13 4900 4M50 FE73D# DN1881RN1451V BL1070PN3513FN6653FN6722 DN1881 FN6653BL1060 FN4466
02.04~11.10 4900 4M50-T FE71D RN1451V PN3513 DN1881 BL1060FN6653 FN4466
02.04~12.06 4900 4M50-T FE72D RN1451VRN1262V PN3514PN3513 DN1881 FN6653FN6602BL1060
06.02~12.10 4900 4M50-T FE83D RN1451V PN3513FN6653BL1060 FN6653 FN4466FN4443
06.00~06.02 5200 4M51 FE51EB RN1451V PN3407 FN6653BL1060 FN4443
10.97~05.99 5200 4M51 FE562 RN1451V PN3407 FN6653BL1060 FN4443
05.02~12.04 5200 4M51 FE70E RN1451V PN3513PN3514 FN6602BL1060PN3514PN3513FN6653 FN4443
05.02~12.04 5200 4M51 FE73E RN1451V PN3513 FN6653BL1060 FN4443
05.02~08.04 5200 4M51 FE82E RN1451V PN3513BL1070 DN1110 FN6722 FN4443

MITSUBISHI   »   Fuso

09.06~ 4900 4M50T FE84D RN1451V PN3513 RN1927V PN3513

MITSUBISHI   »   Rosa

01.05~ 4900 4M50-T BE64DG RN1451V PN3407 DN1881 FN6653BL1060 FN4443
08.97~04.99 5200 4M51 BE632# RN1451VRN1262V PN3407PN3349 DN1881 FN6653BL1060 FN4443
