ROTOR DISC » RN1359V

Specification

Type
Vented
Disc Thickness (Max)
35
Num. of holes
5
Height
91
Centering Diameter
114
Front/Rear
Front
Pitch Circle Ø
140
Outter Ø
269
Drum Ø:
114.8
Disc Thickness (Min)
33
Structure Material
G3000

Cross Reference

NISSAN
40206-0T301
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.91~10.93 3000 BD30 W2H41 RN1359V FN1197PN2368 BL1055FN4451FN1197 FN3340
10.91~06.95 4200 FD42 DG2H41 RN1504VRN1359V PN2368FN4451 FN1202BL1055 FN1244

Exemption from liability: the catalog data is advisory and can be used for reference only
