BRAKE SHOE » FN11909
Specification
Radius
89
Width
37
Pcs In Set
4
Thickness
5.5
Cross Reference
FMSI
S749
HYUNDAI
58305-25A00
KASHIYAMA
K11165
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.99~07.02 | 1300 | G4EA | CG 5DR HB RHD | RN1221V | PN0091 | DN1473DN1471 | FN11189FN11909 | |
| 09.99~07.02 | 1300 | G4EA | CG SDN LHD | RN1221V | PN0091 | DN1473DN1471 | FN11189FN11909 | |
| 09.99~07.02 | 1300 | G4EA | HB LHD | RN1221V | PN0091 | DN1471DN1473 | FN11189FN11909 | |
| 01.00~07.02 | 1300 | G4EH | LC | RN1221V | PN0091 | DN1473DN1471 | FN11189FN11909 | |
| 04.02~06.06 | 1500 | D3DA | C# | RN1027V | PN0091 | FN11909 | ||
| 04.02~06.06 | 1500 | D3EA | LC | PN0091 | FN11909 | |||
| 09.99~10.02 | 1500 | G4#K | CF | RN1027V | PN0091 | FN11909 | ||
| 09.99~07.02 | 1500 | G4#K | CG | RN1027V | PN0091 | DN1473DN1471 | FN11909FN11189 | |
| 07.99~04.03 | 1500 | G4EB | CH LHD | RN1221V | PN0091 | DN1471 | FN11909 | |
| 09.99~07.02 | 1500 | G4EB | CH RHD | RN1221V | PN0091 | DN1471DN1473 | FN11189FN11909 | |
| 03.01~07.02 | 1500 | G4EB | LC (RUS) | RN1221V | PN0091 | DN1473DN1471 | FN11909FN11189 | |
| 04.01~07.02 | 1500 | G4EC-G | LC (RUS) | RN1221V | PN0091 | DN1473DN1471 | FN11909FN11189 | |
| 01.00~06.06 | 1600 | G4ED | LC | RN1221V | PN0091 | DN1471DN1473 | PN0436FN11909FN0617 |
