ROTOR DISC » RN1256V
Specification
Type
Vented
Disc Thickness (Max)
22
Num. of holes
5
Height
38.6
Centering Diameter
69
Pitch Circle Ø
114.3
Front/Rear
Front
Outter Ø
285
Disc Thickness (Min)
20.4
Drum Ø:
145
Structure Material
G3000
Cross Reference
MITSUBISHI
MR334996
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.98~03.05 | 1600 | 4G18 | H65W GEN LHD | RN1256V | PN3417 | DN1358 | FN6723 | |
| 11.98~03.05 | 1600 | 4G18 | H65W GEN RHD | RN1256V | PN3417 | DN1358 | FN6723 | |
| 08.99~05.00 | 1800 | 4G93 | H61W | RN1256V | PN3417 | DN1358 | FN6723 | |
| 03.98~09.02 | 1800 | 4G93 | H66W | RN1256V | PN3417 | DN1358 | FN6723 | |
| 08.99~06.00 | 1800 | 4G93 | H71W | RN1256V | PN3417 | DN1358 | FN6723 | |
| 03.98~06.07 | 1800 | 4G93 | H76W | RN1256V | PN3417 | DN1358RN1242 | PN3174FN6723 | FN0808 |
| 06.98~06.07 | 1800 | 4G93 | H76W JPN | RN1256V | PN3417 | DN1358 | PN3174FN6723 | FN0808 |
| 05.00~09.02 | 2000 | 4G94 | H62W | RN1256V | PN3417 | DN1358 | FN6723 | |
| 05.00~07.04 | 2000 | 4G94 | H67W | RN1256V | PN3417 | DN1358 | FN6723 | |
| 05.00~09.02 | 2000 | 4G94 | H72W | RN1256V | PN3417 | DN1358 | FN6723 | |
| 05.00~06.07 | 2000 | 4G94 | H77W | RN1256V | PN3417 | DN1358 | FN6723 | |
| 02.00~12.05 | 2000 | 4G94 | H77W GEN | RN1256V | PN3417 | DN1358 | FN6723 | |
| 05.00~06.07 | 2000 | 4G94 | H77W JPN | RN1256V | PN3417 | DN1358 | FN6723 |
